1000kg Mecanum Wheel

[[MetaDescription]]

Product Features:

RoboCT integrated mecanum wheels is a brand-new mecanum wheels, which consist of hub motor, gearbox, encoder, hall sensor, and shock absorber system. All-in-one design contributes to its high compact structure and easier installation. And this innovative design makes its application scenarios wider.

1. Omni-directional wheel; even sideways and spin rotation movement

2. Motor built-in mecanum hub wheel

3. Compact structure & easy for assembly

4. Strong & stable

Flexible & maneuverable

Application Scenario：

The precise control of the mecanum wheel makes it easy to operate even in a narrow and defined space, especially in the heavy-duty industry. It is widely used in mecanum wheel robot, mecanum drive robot, mobile robots, warehousing and logistics robots, AGV, AMR, intelligent parking equipment, intralogistics robots and other fields to meet the needs of different industries such as industrial, scientific research, commercial, medical, etc.

Technical Parameters

Model	CTM300-7	CTM300-7R			Model	CTM300-7	CTM300-7R
Picture					Rated Output Velocity (rpm)	150	81	130	175
Diameter	180 MM	180 MM			No-load Velocity (rpm)	400	113	164	212
Roller Material	Casting Polyurethane	Casting Polyurethane			Rated Torque (NM)	7	16
Rated Payload	200 KG	300 KG			Peak Torque (NM)	10	30
Max Payload	300 KG	400 KG			Gearbox	×	√
Rated Voltage (V)	24-48	24	36	48	Encoder	Incremental Magnetic	Incremental Magnetic
Rated Power (W)	173	137	219	295		4096 Line	4096 Line
Efficiency	78%	76%	80%	82%	Hall Sensor	√	√
Rated Current (A)	12.4	7.55	7.57	7.52	Ambient Temp. (℃)	-20~55	-20~55

About RoboCT：

RoboCT founded in 2017, is a technology-driven enterprise, takes technology innovation as the core driving force, and committed to exoskeleton robot technology, robot core components and intelligent control technology. RoboCT owns more than 140 independent intellectual property rights and more than 30 awards at home and abroad. RoboCT motorized mecanum wheel, mecanum mobile robot, precision motion control and robot core components serves over 30 countries in worldwide. CE, ISO9001, ISO14001, ISO45001, ISO27001, ISO13485, and ISO 20000 certified.

FAQ：

1) What is included for one set RoboCT mecanum wheels?
--Different from SS mecanum wheel of other supplier, which has no motor and other electrical parts inside. One set RoboCT integrated mecanum wheels includes 4 pcs aluminum mecanum wheels, which integrates motor, gearbox (in CTM300-7R), encoder, hall sensor, and shock absorber system in each wheel.

2) Factory or trader?
--We have our own factory over 4000 square meter. Producing motorized mecanum wheels, hub motor, robot joint, mecanum robot, and exoskeleton robot.

3) Why should I purchase mecanum wheel from RoboCT?
--RoboCT is a leading robotics company in China, over 20 R&D engineers in-house, contributing to a super-compact mecanum wheel, which enables you to assemble and use it in a very easy way. Mecanum wheels can move in all directions, are made of high quality aluminum by machining, strong and stable. We have experienced engineering and technical support, serving over 30 countries for 10 years.

4) What is the delivery time?
--15 days for samples and for mass production, please contact us for detailed information. Usually by air express FedEx, DHL, UPS...
